使用与详细介绍/Brief Introduction：

全智能轴向液压泵泵式膏体酱装灌机我是你公司融入市面需要联合开发的新厂品。该选果机分为SUS304不锈钢材料轴向液压泵泵式计量校准泵施行装灌，且集智能上盖、智能旋盖、机电专业电力设备为一体式，成本实惠，占地赔偿占地小，宽泛软件应用于生物制药、食材、农约、化工新材料、摄影品等行业领域的透明液体木箱，符合国家GMP规程追求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

特色/characteristic：

◆用注塞泵式记量泵程序执行装罐，适用性很多浓稠度介质液体，导致精度更高；泵的组成部分用快接式拆下来医院，为了方便除垢、紫外线消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式压力容器检验泵活塞杆环才质随着该行业及粘液化学物质的与众不同选取了硅聚氨酯材料，四氟丁二烯或任何才质，个性化商务活动选取了瓷质才质。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调节设计，直流变频空调调压，定时化程度较高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装线，自然计算功能键。Lack of bottle filling, automatic counting function◆装量的更改快捷，可是一次的更改另一个计量检测校准泵的充填量，也可针对于个个计量检测校准泵开展微幅的更改；作业简单便捷，的更改尽快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆灌装生产线线针头有防渗漏平衡装置，充填时入侵瓶底灌装生产线线，变慢上升的，避免裂痕。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆电脑整机可适合各种不同金桥铜业跨接线的截面积大小的瓶盖，整改简约，可在短暂间内做好。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆空机按GMP条件开发。The machine designed according to the requirements of GMP

技木主要参数/technic parameter：

选用塑料瓶规模Size of bottles	20-1000ml（可根据条件生产厂家）20-1000 - ml (according to your need）
采用塑料瓶子直径为Apply the bottle diameter	¢20-¢150mm
符合盖子規格Apply the lid specifications	¢20-¢70mm
产出程度 production capacity	四头灌装线：1000-2500瓶/小时候 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/个钟头 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/天 12 head filling: 4000-6000 bottles per hour
装量计算误差The load error	±1%
旋盖适合率Screw cover percent of pass	≥99%
24v电源power supply	380V，50HZ
公率power	3.0KW
安全阀gas sources	0.4-0.75MPA
极限速度保持speed control	调频调节variable speed
