种类与概况/Brief Introduction：

超声波焊接机是转变服食液夹层破璃制瓶的新货品，彻底消除很好解决了往日服食液夹层破璃制瓶的异常情况结果。这种灌封机用到的的pp塑料瓶子，不当不必须要洗瓶机、烘烤机，更不必须要紫外线灯消毒，就可以间接灌封。该选果机全智能理瓶、进瓶、罐装，罐装量维持性，无漏滴，无瓶不罐装。上盖、密封率能达到100%。此机高技术先进性，体型大小小、正常运作维持性、燥音低，进行操作售后维修、拆洗快捷等特性，全部按照GMP标准的。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本规格有高转速和飞速哪几种产出量供您选定。Note: this model has two kinds of low speed and high-speed production for your choice.

显著特点 Characteristic

◆滤油机适用性于各样易折瓶口服药液压力容器检验灌装设备和封膜。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆整个电嚣开关元件均适用著名店牌该品牌。All electrical components adopt famous brand◆远程服务器进行客观事物不便，无瓶不装罐，计量校准*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料管瓶灌封机的主要结构的与关键技术Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型服食液易折塑胶片瓶灌封机主要的理瓶器、理盖器、主齿轮制动系统化、微信同步带缝隙送小瓶裝置、瓶子检漏裝置、装罐中介装置、消除裝置、热熔胶封中介装置、气动式机械厂指尖夹瓶中介装置、交流伺服变频电动机变频电动机缝隙上瓶中介装置与出瓶中介装置等结构。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆电脑实用的服食液易折金属瓶、盖有的是定净化后的区生育的，应用药粉材同意证，于是瓶身与底盖经传承和"去外包公司"后可随时进去灌封间。根据理盖器、理瓶器的智能定项收集整理，消除正向底盖及瓶身底口朝下的瓶，使定项后的包材喂料有的规则地进去输送机正轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向就业后口服药液易折pp塑料饮料瓶在输送带轨道组件里排Directional oral liquid after folding plastic bottles in conveying rail out easily

水平数据technical parameters：

型号model	NLGFY-40	NLGFY-80
装量比率The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封好率Hot sealing intensity	》99%
装量计算误差The load error	《1.5%
磨损率damage rate	《1.0%
电机功率power	2KW	3KW
开关电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
毛重 Weight	700Kg	800Kg
