应用领域与百科/Brief Introduction：

该线由渐近线式螺栓洗瓶烤干二合一机、服用液装灌轧盖机二台单人游戏组合，包括洗掉、干杀菌和装灌封口处几个作业区，集体可一体化工作，也可单人游戏运用。可到位淋水、超声难以清理波洗掉、冲水、冲气、烤干杀菌、一系列冷却、装灌、理盖、戴盖、轧盖等流程。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

优点和缺点/Characteristic：

运用超声心动图波进行维护清洁及水汽跳变喷洗、远红外中高温杀菌、空头装罐与封好等技艺。整线协作半自动抑制。方法很简单简单方便，保持了有限公司一梯化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

科技性能参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适于型号 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(当中日常事业36Kw)(including normal working 36 kw)
工具重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
